OL Integration
Legacy logic to APIs and events
Turn the programs, transactions, screens, and data that run your business into tested APIs and events, published as REST, Kafka, IBM MQ, SOAP, and more.
How it works
Connect, design, then publish
01Connect
Backend operations become tested assets
Create a module for a connector, bind a connection, and add assets from the live system or from source: a COBOL program, a stored procedure, a BAPI, a REST operation, or a 3270 or 5250 screen. Each asset is versioned and testable.
02Design
A contract and flows on top
Build the contract from assets, an imported OpenAPI or WSDL, or a recorded terminal trail, and let AI add readable names and descriptions. Orchestrate the backend calls on a visual flow canvas.
03Publish and operate
One design, many endpoints
Generate the same contract as OpenAPI, Kafka, serverless, SOAP, IBM MQ, file, or DB poller endpoints, test it in Test Center or CI, deploy it, and watch it in Grafana dashboards.
Key features
From a backend operation to a running, monitored service
01 / IBM Z
Mainframe connectors
CICS through the OpenLegacy adapter or CICS Transaction Gateway, IMS, Natural, DB2 for z/OS, VSAM, 3270 screens, Micro Focus COBOL, and Heirloom CICS.
02 / IBM I
IBM i connectors
Program calls from RPG, COBOL, or PCML, 5250 screens, data queues, DB2 for i, and JD Edwards business functions.
03 / ENTERPRISE
SAP, Oracle, and SOAP
SAP BAPIs through JCo, Oracle stored procedures over JDBC, and existing SOAP services imported from WSDL.
04 / ASSETS
Versioned, testable assets
Each backend operation is an asset with typed input and output trees. Methods pin an asset version and are upgraded deliberately when it changes.
05 / CONTRACT
Contract-first, friendly APIs
Design the contract as the API, then enrich it with AI: readable names, descriptions, and auto-mapping that people and agents can use.
06 / RPC FLOWS
Visual flow orchestration
Invoke program, database, SOAP, REST, and messaging assets with mapping, conditions, for-each, parallel paths, and reusable subflows.
07 / SCREENS
Terminal journeys as methods
Automate 3270 and 5250 journeys: identify the screen, send a key, capture fields, branch, and reuse login or navigation as a subflow.
08 / ENDPOINTS
Multi-technology endpoints
One contract generated as OpenAPI, Kafka, serverless, SOAP, IBM MQ, file, or DB poller, with each technology's settings kept when you switch.
Video / Contract with AI
Create a project and an auto-generated contract
A CICS accounts module holds RPC assets for create, read, update, delete, and list. The module is added to a new accounts API project, and Create Contract generates it automatically, with AI enriching the descriptions and input and output metadata before the contract is created.
Events from the source
Database pollers and IBM i change data capture
A DB poller runs a SQL query on Oracle, SQL Server, DB2 for z/OS, or DB2 for i on a schedule and sends each new or flagged row through a flow. IBM i CDC reads the journal for selected tables, by table or by committed transaction, and turns each insert, update, and delete into JSON a flow can send to Kafka, REST, or another step.
AI and MCP
The same operations, as agent tools
AI generates enriched contracts, suggests field names and descriptions, auto-maps contracts to assets, and assists in the Designer. Published APIs can be installed in OL Gene as agent tools, so AI agents and MCP clients call the same governed operations under organization credentials.
Video / Generate the service
Publish contract methods and generate a no-code REST service
The CICS accounts contract lists list, get, create, update, and delete methods. The methods are published from the contract task list, Generate Service selects the container REST generator, and the solution page explains deploying the contract as an OpenAPI REST service.
Test and automate
Test plans in Hub or CI, and a CLI for the pipeline
Test Center runs ordered plans built from saved flow test cases, from the Hub UI or from CI, and keeps the history of every run. The ol CLI creates modules, pushes metadata, tests assets, generates services, and deploys from scripts, so the path from a legacy asset to a running service can be repeated without the UI.
Operate
Grafana dashboards for deployed APIs
Runtime metrics and logs for deployed APIs appear in Grafana, embedded in Hub and scoped by tenant, project, environment, and instance, so teams can check whether a published API is healthy in test and production from the same runtime view.
Video / Testing
Test a contract method with cases and assertions
Selecting the list-accounts method runs a flow test and shows the JSON response. A named test case is saved with its input JSON and optional variables, and an HTTP 200 status assertion is added so the case can be replayed from Test Cases.
At a glance
Design once, publish the way each consumer needs
Endpoint technologies
OpenAPI, Kafka, serverless, SOAP, IBM MQ, file or SFTP, and DB poller.
Flow types
RPC flows for program and data calls, Screens flows for 3270 and 5250 journeys.
DB poller sources
Oracle, SQL Server, DB2 for z/OS, and DB2 for i.
Ways to run tests
From the Hub UI or from CI with the ol CLI, with history kept for both.
ECOSYSTEM
Connectors for the systems you already run
Legacy and on-prem backends on one side, APIs, events, and agents on the other.
FAQ
Common questions
Which backends can OL Integration connect to?
IBM Z (CICS, IMS, Natural, DB2, VSAM, 3270 screens, Micro Focus COBOL, Heirloom CICS), IBM i (RPG, COBOL, PCML, 5250 screens, data queues, DB2 for i, JD Edwards), SAP, Oracle, SOAP, and other connectors including IBM MQ, Kafka, ActiveMQ, REST and OData, JDBC, files and SFTP, ISO-8583, Temenos T24, Tuxedo, and CORBA.
Can one integration be published in more than one way?
Yes. You design the contract and flows once, then generate them as OpenAPI, Kafka, serverless, SOAP, IBM MQ, file, or DB poller endpoints. Each technology keeps its own settings when you switch.
What happens when a backend program changes?
Editing an asset creates a new version. Methods stay pinned to the version they use until you upgrade them, and Hub offers to move methods forward after the save.
Can AI agents use the APIs?
Yes. Published APIs can be installed in OL Gene as agent tools, so AI agents and MCP clients call the same governed operations under organization credentials.
Can we automate it in CI/CD?
Yes. The ol CLI creates modules, pushes metadata, tests assets, generates services, and deploys, and Test Center plans can be run from CI.
